character LCD module |20x4 |Monochrome STN + | With yellow-green side backlight | Arduino display | Transflective| ST7066U | 3.3v/5.0v

▶ Model: HTM2004A-11Y-A5P

▶ Type: character LCD module
▶ Display content: 20x4 characters
▶ Overall dimensions (mm): 98.0x60.0x14.2
▶ VA size (mm): 76.0x25.8
▶ AA size (mm): 70.4x20.8
▶ Point spacing mm: 0.6x0.6
▶ Application: Industrial instrumentation
▶ Viewing angle: 6H
▶ Backlight type:yellow/green light
▶ Number of PINs: 16PIN
▶ Interface mode: MCU/8bit
▶ Special instructions: Anti-static ESD 8KV
▶ Working temperature: -20~70℃
▶ Power supply voltage: 5.0v
▶ Driver chip: ST7066U

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Share to:

Prev Back Next

Related Accessories

Monochrome COG/Graphic COB/Character COB/OLED module/E-paper module/Segment screen 8051 test board
Monochrome COG/Graphic COB/Character COB/OLED module/E-paper module/Segment screen STM32 test board
Character graphic dot matrix module dedicated adapter board
Single Row Pin Header Connector
COB 20-pin cable base/character/graphic dot matrix

Product Description
Customized Services
Attributes

character LCD module |20x4 |Monochrome STN + | With yellow-green side backlight | Arduino display | Transflective| ST7066U | 3.3v/5.0v

character LCD module 20x4 character LCD displays characters in dark pixels on a bright yellow/green background. This cross-screen LCD monitor can be used in ambient or low-light environments, includes visible yellow and green backlighting, and offers a wide operating temperature range of -20 to 70°C. Best viewing angle for HTM2004-11 Y-A5P monitor is now 6 o'clock. The power supply voltage is 3.3V or 5.0V, and can be used with development boards such as Arduino. It is also RoHS compliant.

Project	Specification content	Unit
model	HTM-2004A-11Y-A5P
words × lines	20 Words × 4rows	dots
Module size	98.0 × 60.0 × 14.2 (MAX)	mm
VA size	76.0（W） × 25.8（H）	mm
AA size	70.4 × 20.8	mm
Point (pixel) spacing	0.60（W） × 0.60（H）mm	mm
IC	ST7066U
Applied voltage	5V	V
backlight	Yellow/green backlight
model	STN+
Drive mode	1/16 duty cycle
type	Character LCD Module
Polarizer type	Transflective
