15.0 inch TFT LCD Display | 1024x768 TFT color display
Product highlights:
15.0 inch TFT LCD Display High-definition display: 15-inch large screen, XGA resolution (1024×768 pixels), providing a clear and delicate visual experience.
Wide viewing angle design: Supports full viewing angle (CR≥10 @ R/L/U/D 80°/80°/80°), ensuring a perfect picture from any angle.
High brightness and contrast: Brightness up to 400 cd/m², contrast ratio 800:1, suitable for various lighting environments.
Fast response: response time ≤25ms, dynamic images are smooth and without smear.
Low power consumption design: working voltage 3.3V, power consumption as low as 1.687W (all white screen), energy saving and environmental protection.
Rugged and durable: the surface is treated with AG+3H, scratch-resistant and wear-resistant, suitable for harsh industrial environments.
15.0 inch TFT LCD Display Applicable scenarios:
Industrial control panel
Medical equipment display
In-vehicle navigation system
Smart home terminal
Outdoor advertising display
15.0 inch TFT LCD Display Core advantages:
LVDS interface: supports high-speed data transmission and strong compatibility.
Wide temperature operation: operating temperature range -20℃～70℃, adaptable to extreme environments.
Long-life backlight: LED backlight life is up to 50,000 hours, long-lasting and stable.
RoHS certification: meets environmental protection standards, safe and reliable.
Usage suggestions:
Avoid displaying static images for a long time. It is recommended to refresh the content every 2 minutes or enable dynamic screen saver to prevent image retention.
15.0 inch TFT LCD Display is Suitable for scenes with high brightness and high contrast requirements, providing excellent visual expression.
