Character LCD Module |2X16 STN+ Gray Display with White Side Backlight Display-Arduino

Character LCD Module |2X16 STN+ Gray Display with White Side Backlight Display-Arduino

▶ Model: HTM1602A-11W-A5P

▶ Type: Character LCD Module
▶ Display content: 16x2 characters
▶ Overall dimensions (mm): 80.0x36.0x13.1
▶ VA size (mm): 64.5x15.8
▶ AA size (mm): 55.8x10.64
▶ Point spacing mm: 0.62x0.64
▶ Product application: industrial control
▶ Viewing angle: 6H
▶ Backlight type or: White
▶ Number of PINs: 16PIN
▶ Interface mode: MCU/8bit
▶ Special instructions: Anti-static ESD 8KV
▶ Working temperature: -20~70℃
▶ Power supply voltage: 5.0v
▶ Driver chip: ST7066U
Product ConsultationDatasheets Download Shopping
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Share to:

Prev Back Next

Related Accessories

Monochrome COG/Graphic COB/Character COB/OLED module/E-paper module/Segment screen 8051 test board
Monochrome COG/Graphic COB/Character COB/OLED module/E-paper module/Segment screen STM32 test board
Character graphic dot matrix module dedicated adapter board
Single Row Pin Header Connector
COB 20-pin cable base/character/graphic dot matrix

Product Description
Customized Services
Attributes

Character LCD Module |2X16 STN+ Gray Display with White Side Backlight Display-Arduino
Character LCD Module 16x2 LCD display shows up to 32 characters as two rows, each with sixteen characters of blue, dark pixels on a light gray background. This transflective STN positive Liquid Crystal Display includes a side white LED backlight allowing it to be visible with backlight on or with ambient light while offering an optimal 6:00 view.
HTM1602A-11W-A5P display has a wide operating temperature range from -20 to 70 degrees Celsius, a built-in ST7066U controller, operates at 5V supply voltage with low Power of 20mA, and adheres to the highest quality standards. Whether you are looking to develop a high-quality product or use it for a personal project, this 16 character, 2 rows, Arduino compatible character LCD offers quality and performance with low power consumption.

project	Parameter Description	unit
model	HTM1602A-11W-A5P
Character display line	16x2 characters	dots
Module Size	80.0x36.0x13.1	mm
VA size	64.5 (W) × 15.8 (H)	mm
Effective (AA) area	55.8x10.64	mm
Point (Pixel) Size	0.52×0.54mm	mm
Pixel spacing	0.62 × 0.64	mm
IC drive	ST7066U driver
supply voltage	5V	V
Backlight	White backlight
mode	STN+ gray
Drive mode	1/16 duty cycle
type	Character LCD module
characteristic	Transflective polarizer
