ESP32-P4 Driver Board For LCD Display

ESP32-P4 Driver Board For LCD Display

▶ Model：
ESP32-P 4-DEMO-A02-V0

▶ Type: Development Board/Evaluation Board
▶ Dimensions: 90.00 x 100.00 x 16.30 (mm)
▶ Touch Interaction: Supported
▶ Data Storage: SD Card
▶ Applications: Smart Home, Industrial Control, IoT
Product ConsultationDatasheets Download
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Share to:

No Back Next

Product Description
Customized Services
Attributes

Product Overview
This development board is powered by the Espressif ESP32-P4 chip, a high-performance MCU supporting AI instructions and multimedia processing. Featuring a compact design, the board integrates display, touch, communication, storage, and various high-speed expansion interfaces, aiming to provide a one-stop hardware solution for smart interaction, industrial HMI (Human-Machine Interface), and edge computing devices.

Core Hardware and Display System
Main Control Chip: Powered by the ESP32-P4, offering robust computing power and graphics rendering performance.

Display Interface: Features an onboard standard 40-pin RGB LCD interface for directly driving parallel RGB displays; also includes a MIPI adapter connector compatible with MIPI-DSI high-definition screens, meeting diverse resolution and refresh rate requirements.

Touch Interaction: Supports CTP (Capacitive Touch Panel) functionality; connects to touch screens via I2C or SPI interfaces to enable multi-touch operations.

Vision Expansion: Provides a CSI camera interface for image sensor connectivity, suitable for visual recognition and video capture applications.

Communication and Connectivity
Wireless Communication: Integrates the ESP32-C6 Wi-Fi/BT module, supporting 2.4 GHz Wi-Fi 6 (802.11ax) and Bluetooth 5.3 (LE Audio) to provide low-power, highly reliable wireless connectivity for IoT applications.

Wired Network: Includes an onboard Ethernet interface for wired network access, meeting industrial-grade requirements for stable data transmission.

Debugging and Expansion: Exposes RGB pin headers for signal expansion; provides USB OTG and USB UART interfaces for host-mode communication and firmware debugging/flashing, respectively.

Storage and Power Supply
Data Storage: Equipped with an SD card slot supporting high-capacity external storage, facilitating the storage of font libraries, images, or firmware upgrade files.

Display Backlight: Integrates a backlight driver module, allowing for flexible LCD brightness adjustment to optimize power consumption and visual clarity.

Development and Debugging Support
Features an onboard UART0 serial port; combined with the USB UART interface, it enables convenient log output and command-line interaction.

Exposes multiple GPIO expansion pins (such as RGB headers) to facilitate the connection of sensors, buttons, or peripheral modules.

Typical Application Scenarios
- Smart home central control panel
- Industrial HMI (Human-Machine Interface) panel
- Edge AI vision terminal (integrated with a camera)
- IoT gateway and data display terminal
- Portable multimedia playback device
