1X16 character mono LCD Display | FSTN+Gray background with White backlight-Arduino

1X16 character mono LCD Display | FSTN+Gray background with White backlight-Arduino

▶ Model: HTM-1601A-31W-A5P

▶ Type: Standard COB character LCD
▶ Display content: 16x1 characters
▶ Overall dimensions (mm): 80.0x36.0x13.1
▶ Viewing window size (mm): 64.5x16.0
▶ Display size (mm): 59.46x5.96
▶ Point spacing mm: 0.65x0.75
▶ Product application: industrial control
▶ Viewing angle: 6H
▶ Backlight: white light
▶ Number of PINs: 16PIN
▶ Interface: MCU
▶ Special instructions: Antistatic ESD 8KV
▶ Working temperature: -20~70℃
▶ Supply voltage: 5.0v
▶ Driver chip:ST7066U

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Prev Back Next

Related Accessories

Arduino adapter board/suitable for Arduino development board COB/character/graphic dot matrix
Single Row Pin Header Connector
COB 20-pin cable base/character/graphic dot matrix

Product Description
Specification
Attributes
Download Related Materials

HTM-1601A-31W-A5P | 1x16 Character Display | Reflective LCD | FSTN (+) Positive Gray Display | Arduino Display

This HTM-1601A-31W-A5P displays dark pixels on a bright white background. Transmissive LCD mode allows this display to be viewable in any environment, including low brightness, ambient and unusually bright environments. It offers a wide operating temperature range from -20 to 70 degrees Celsius and operates on a 5V power supply. Comes with British and Japanese standard supplies. The display is compatible with Arduino and other popular development frameworks. The character display shoes feature dark pixels on a bright white background. Transmissive LCD mode allows this display to be viewable in any environment, including low brightness, ambient and unusually bright environments. It offers a wide operating temperature range from -20 to 70 degrees Celsius and operates on a 5V power supply. Comes with British and Japanese standard supplies.

Connector Customization:

Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require.

PCB Modifications:

Choose from a variety of changes to the PCB's shape, size, pinout, and component layout to make it perfect for your application.

Backlight color customization:

The module backlight has a variety of combinations to choose from, without backlight or with yellow-green/blue/white/amber/red/RGB backlight options. There are 48 effects. You can click on the customization page for reference.

Font library customization:

Provides a variety of font libraries, including English/Japanese, Western Europe, Eastern Europe, Scandinavian Europe, Cyrillic (Russian), Hebrew/Arabic, etc.

Cable Customization:

Adjust the length, position, and pinout of your cables or add additional connectors. Get a cable solution that’s precisely designed to make your connections streamlined and secure.

parameter	Specification content	unit
model	HTM-1601A-31W-A5P
resolving power	16words × 1line	dots
Module Size	80.0（W） × 36.0（H） × 13.1 （D）mm	mm
Visible (VA) area	64.5x16.0mm	mm
Effective (AA) area	59.46x5.96	mm
Pixel spacing	0.60 × 0.70	mm
IC	ST7066U
Application voltage	5.0V	V
Backlight	White backlight
display mode	FSTN+
Drive mode	1/16 duty cycle
product type	Character LCD
characteristic	Transflective poparizer
