TFT-H035A33QVIST8N54 | 3.5-inch 320x240 resolution TFT LCD screen with RGB interface | IPS full-viewing-angle TFT LCD | High-brightness TFT LCD visible in sunlight

This high-performance 3.5-inch TFT LCD display is designed for high reliability and clarity, making it an ideal display solution for demanding industrial and outdoor applications. Its standout feature is an ultra-high brightness backlight of 800 cd/m², combined with advanced IPS full-viewing-angle technology, ensuring excellent readability and consistent color performance even under direct sunlight and at wide viewing angles. Designed to withstand harsh environments, the module boasts a wide operating temperature range of -30 to 80°C and robust 8KV ESD protection, guaranteeing reliable operation in various complex conditions.

This 3.5-inch TFT LCD display offers a 320x240 pixel resolution, delivering crisp and detailed images, making it ideal for displaying critical data and user interfaces on outdoor equipment and central control systems. Its compact size allows for seamless integration into space-constrained designs. A standard 54-pin RGB interface ensures convenient connectivity and compatibility. This 3.5-inch TFT LCD boasts exceptional durability and visual performance, making it an outstanding and reliable choice for developers seeking a monitor that won't fail at critical moments.

FAQ from Purchasing:

Question 1: I need a display screen that is clearly visible even in bright outdoor environments. What solution does this 3.5-inch 320x240 resolution TFT LCD screen offer?

Answer 1: This is a key challenge we focused on solving when designing this product. Our 3.5-inch 320x240 resolution TFT LCD screen features a backlight with a brightness of up to 800 cd/m². This high brightness effectively suppresses screen glare, ensuring that all data, readings, and interface elements remain clearly legible even in direct sunlight, thereby improving operator safety and efficiency in outdoor applications.

Question 2: Control panels are viewed by multiple operators from different angles. How does this 3.5-inch 320x240 resolution TFT LCD screen ensure that everyone can see an accurate image?

Answer 2: This common problem in control rooms is solved by the IPS (In-Plane Switching) technology integrated into this 3.5-inch TFT LCD screen. This 3.5-inch 320x240 resolution TFT LCD screen offers a 178-degree viewing angle without color shift or contrast inversion. This means that regardless of the operator's position relative to the screen, they can see consistent and accurate content, thus avoiding misreading critical information.

Q3: When applications face extreme temperature fluctuations and the risk of electric shock, can this 3.5-inch 320x240 resolution TFT LCD screen reliably withstand such harsh environments?

A3: Yes, maintaining reliability in harsh environments is a core design principle. This 3.5-inch TFT LCD screen operates perfectly within a wide temperature range of -30°C to 80°C, whether in the cold of winter or the heat of summer. Furthermore, its integrated 8KV ESD protection effectively prevents electrostatic discharge, significantly improving the module's lifespan and reliability in noisy industrial environments.
