10.1-inch 1024x600 IPS high-definition TFT color display | RGB interface
Core advantages
High-definition display, precise presentation
10.1-inch large screen, resolution of 1024×3RGB×600, delicate and clear picture, details are clearly visible.
800:1 high contrast ratio, support 85° full viewing angle (left/right/up/down), ensure color consistency at different angles, no blind spots in vision.
50% NTSC color gamut, accurate restoration of red (Rx=0.605, Ry=0.336), green (Gx=0.297, Gy=0.552), blue (Bx=0.139, By=0.132) three primary colors, full and realistic colors.
Industrial-grade reliability
Wide temperature operation: adapt to harsh environments of -20℃~70℃, storage temperature range of -30℃~80℃, no fear of extreme challenges.
Super durable: Passed multiple reliability tests such as high temperature and humidity (60℃/90%RH), thermal shock (-30℃↔80℃ cycle), mechanical vibration (8-33.3Hz), etc. to ensure long-term stable operation.
Anti-static design: Contact discharge ±4KV, air discharge ±8KV, protect the module from static interference.
Flexible interface and efficient drive
Support TTL 24-bit parallel interface, compatible with mainstream controllers, easy integration.
Adopt EK79001+EK73215 driver IC, with 30ms fast response time, dynamic picture without smear, smooth without delay.
Multiple scanning modes: support left/right/up/down scanning direction switching (L/R, U/D pin control), adapt to different application scenarios.
Energy-saving backlight design
White LED backlight, brightness up to 750cd/m² (typical value), power consumption as low as 17V/180mA, taking into account energy efficiency and display effect.
Typical application scenarios
Industrial control: PLC human-machine interface, instrument display
Medical equipment: monitor, diagnostic instrument screen
In-vehicle display: in-vehicle navigation, engineering machinery control terminal
Intelligent terminal: self-service machine, POS cash register system
Professional service support
Customized service: support model, interface, and appearance customization to meet personalized needs.
Technical guarantee: provide complete initialization code (if necessary), pin definition and circuit design reference to lower the development threshold.
Quality commitment: strictly follow ISO standard production, and carry out quality control from R&D to delivery to ensure the excellent performance of each module.
