1x16 character LCD modules | DFSTN(-) black background with white backlight

1x16 character LCD modules | DFSTN(-) black background with white backlight | Ardunio

▶ Model：
HTM1601A-47W-A5P

▶ Product type: character LCD modules
▶ Display content: 16x1 characters
▶ Overall dimensions (mm): 80.0x36.0x13.1
▶ View window size (mm): 64.5x16.0
▶ Display size (mm): 59.46x5.96
▶ Point spacing mm: 0.65x0.75
▶ Product application: industrial control
▶ Viewing angle: 12H
▶ Backlight: yellow-green light
▶ Number of PINs: 16PIN
▶ Interface: MCU
▶ Special instructions: Anti-static ESD 8KV
▶ Working temperature: -20~70℃
▶ Power supply voltage: 5.0v
▶ Driver chip:ST7066U
