2 Inch 480x360 TFT LCD Display With RGB Interface

▶ Model: TFT-H020A09YLIST7N40

▶ Type: Standard TFT Display
▶ Display Pixels: 480x360
▶ Dimensions: 46.1x40.96x2.5mm
▶ AA Size (mm): 40.824x30.618mm
▶ Display Inches: 2.0"
▶ Applications: Instrumentation, Portable Electronic Devices
▶ Viewing Angle: IPS Full Viewing Angle
▶ Backlight/Brightness: 700cd/m²
▶ Pinout: FPC-40 pin
▶ Interface: RGB
▶ Special Instructions: ESD 8kV
▶ Operating Temperature: -20°C to 70°C
▶ Supply Voltage: 3.3V
▶ Driver IC: ST7701S

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Share to:

Prev Back Next

Product Description
Customized Services
Attributes

TFT-H020A09YLIST7N40 | 2-inch 480x360 TFT LCD Display with RGB Interface | IPS High Brightness TFT LCD Display
Enhance Your Designs with Our 2-inch 480x360 TFT LCD Display with RGB Interface | High-Brightness IPS TFT LCD Display

Introducing our premium 2-inch 480x360 TFT LCD display, designed to deliver exceptional visual performance and robust reliability for demanding professional and portable applications. This high-brightness module is ideal for designers seeking the perfect balance of compact form factor, stunning clarity, and rugged durability.

At the heart of this module is a crisp 480x360 TFT LCD display. The adoption of IPS (In-Plane Switching) technology ensures a full viewing angle of 85/85/85/85, guaranteeing consistent, accurate color reproduction and impeccable image clarity even when viewed at extreme angles, without inversion or color shift. This makes every interaction with your device intuitive and easy to understand. A standout feature of this 480x360 TFT LCD display is its high brightness of up to 700 nits. This ensures clear visibility even in direct sunlight and bright environments, making it indispensable for outdoor instrumentation, industrial handheld devices, and medical monitoring equipment. Furthermore, this 480x360 TFT LCD display boasts exceptional performance, with a wide operating temperature range (-20°C to +70°C) and up to 8kV ESD protection, ensuring stable operation in harsh environments.

Driven by a powerful ST7701S controller and equipped with a standard RGB interface, this 480x360 TFT LCD display seamlessly integrates with a wide range of mainstream processors and FPGAs. Choose this display to bring superior visibility, reliability, and color performance to your next-generation innovations in instrumentation, portable consumer electronics, or advanced industrial control.

Datasheet for Touch Panel,Controller↓

Name	Date	Size
TFT-H020A09YLIST7N40	October 10, 2025	1.42MB

Customized Cables/FPCs: Adjust cable length, position, and pinout, or add additional connectors to suit your needs. Get precisely engineered cable solutions to make your connections more streamlined and secure.

Touchscreen: Enhance your user experience with capacitive or resistive touchscreen technology. We can adjust the glass thickness or shape of the touchscreen to ensure a perfect fit for your design.

Interface Customization: Choose from a variety of interface options or speak with our experts to select the interface option that best suits your project. We can integrate interfaces such as HI, USB, SPI, VGA, etc. into your display to achieve your design goals.

Cover Glass: Custom-cut cover glass for your display for increased durability. Cover glass is available in a variety of thicknesses and optically bonded to protect against moisture and debris.Optional surface treatment: AF (anti-fingerprint oil) / AG (anti-glare) / AR (anti-reflection).

ITEM	PARAMETER DESCRIPTION	UNIT
TFT series	TFT-H020A09YLIST7N40
Diagonal size	2.0”	Inch
Resolution	480x360	Dot
Dimensions	46.1x40.96x2.5	mm
Active area (AA)	40.824x30.618	mm
LCD type	2.0” TFT Module	mm
Display viewing angle	Full View
Aspect ratio	3:2
Backlight type	LED white
TFT driver IC	ST7701S
Brightness	700cd/m2	cd/m2
Operating temperature	-20~70℃	℃
Storage temperature	-30~80℃	℃
