5 Inch TFT LCD Display With RGB Interface | High Birghtness LCD

▶ Model: TFT-H050A21SVISTGN50

▶ Type: 5-inch TFT LCD Display
▶ Display Pixels: 800x480
▶ Dimensions (mm): 120.7x75.8x2.9mm
▶ Active Dimensions (mm): 108.0x64.8mm
▶ Application: Industrial Controllers
▶ Viewing Angle: IPS Full Viewing Angle
▶ Brightness: 1600cd/m²
▶ Interface: RGB
▶ Pinout: 50
▶ Special Instructions: ESD 8kV
▶ Operating Temperature: -30°C to 80°C
▶ Supply Voltage: 3.3V

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Share to:

Prev Back Next

Product Description
Customized Services
Attributes

TFT-H050A21SVISTGN50 | 5 Inch TFT LCD Display With RGB Interface | High Birghtness LCD
Explore our premium 5 Inch RGB TFT LCD display, engineered for demanding industrial applications. This sunlight-readable display boasts an exceptional 1600 cd/m² high brightness and IPS full viewing angle technology, ensuring perfect visibility even in direct sunlight and from wide angles.

The module features a 5 Inch TFT LCD with a sharp pixel resolution . Its robust RGB interface with 50-pin pinout ensures reliable data transmission. Designed for durability, it operates in a wide temperature range of -30°C to 80°C and offers high ESD protection of 8kV.

Equipped with a capacitive touchscreen, it provides intuitive user interaction. With a slim profile of 2.9mm and a 3.3V supply voltage, this 5 Inch TFT LCD Display is the ideal embedded display solution for industrial controllers, HMIs, and outdoor equipment requiring superior performance and reliability.

Datasheet for Touch Panel,Controller↓

Name	Date	Size
TFT-H050A21SVISTGN50	September 09, 2025	2.30MB

Customized Cables/FPCs: Adjust cable length, position, and pinout, or add additional connectors to suit your needs. Get precisely engineered cable solutions to make your connections more streamlined and secure.

Touchscreen: Enhance your user experience with capacitive or resistive touchscreen technology. We can adjust the glass thickness or shape of the touchscreen to ensure a perfect fit for your design.

Interface Customization: Choose from a variety of interface options or speak with our experts to select the interface option that best suits your project. We can integrate interfaces such as HI, USB, SPI, VGA, etc. into your display to achieve your design goals.

Cover Glass: Custom-cut cover glass for your display for increased durability. Cover glass is available in a variety of thicknesses and optically bonded to protect against moisture and debris.Optional surface treatment: AF (anti-fingerprint oil) / AG (anti-glare) / AR (anti-reflection).

ITEM	PARAMETER DESCRIPTION	UNIT
TFT series	TFT-H050A21SVISTGN50
Diagonal size	5.0”	Inch
Resolution	800x480	Dot
Dimensions	120.7x75.8x2.9	mm
Active area (AA)	108.0x64.8	mm
LCD type	5.0” TFT Module	mm
Display viewing angle	Full View
Aspect ratio	3：2
Backlight type	LED white
TFT driver IC	——
Brightness	1600cd/m2	cd/m2
Operating temperature	-30~80℃	℃
Storage temperature	-30~80℃	℃
