4x20 Character LCD Display | DFSTN- Black Background With White Backlight

▶ Model: HTM2004-5-47W-A5P

▶ Type: 4x20 character LCD modules
▶ Display content: 20x4 characters
▶ Dimensions (mm): 77.0x47.0x14.7
▶ VA size (mm): 60.0x22.2
▶ AA size (mm): 55.12x17.56
▶ Pixel pitch mm: 0.47 x 0.51
▶ Product application: industrial control
▶ Viewing angle: 12H
▶ Backlight type:white light
▶ Number of PINs: 16PIN
▶ Interface mode: MCU
▶ Special instructions: Anti-static ESD 8KV
▶ Operating temperature: -20~70℃
▶ Supply voltage: 5.0V
▶ Driver chip: ST7066U

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Share to:

Prev Back Next

Related Accessories

Monochrome COG/Graphic COB/Character COB/OLED module/E-paper module/Segment screen 8051 test board
Monochrome COG/Graphic COB/Character COB/OLED module/E-paper module/Segment screen STM32 test board
Character graphic dot matrix module dedicated adapter board
Single Row Pin Header Connector
COB 20-pin cable base/character/graphic dot matrix

Product Description
Customized Services
Attributes

4x20 character LCD modules | DFSTN- monochrome display | with white backlight | white text on black background | 5.0V | Arduino | st7066u
The 4x20 character LCD modules has white pixels with black markings at the bottom. This LCD display can be clearly displayed in ambient light conditions or in low light conditions with additional light. We offer an operating temperature range of -20 to 70 degrees Celsius and is visible at 12:00. The device has a 5V supply voltage and the control chip is ST7066U, which is compatible with popular development platforms such as Arduino.

Project	Parameter Description	Unit
Name	HTM-2004-5-47W-A5P
Number of dots	20 words× 4lines	dots
Module size	77.0 × 47.0 × 14.7 (MAX)	mm
Visual (VA) area	60.0（W） × 22.2（H）	mm
Effective (AA) area	55.12（W） × 17.56（H）	mm
Dot (pixel) spacing	0.47 × 0.51mm	mm
IC	ST7066U driver chip
Power supply voltage	5.0V	V
Backlight	White light
Display mode	DFSTN-
Drive mode (Duty)	1/16 duty cycle
Type	Character LCD
Features	Transmissive
