What are the resolutions of 10.1-inch TFT LCD Display?
2024-09-29
5104
China Custom Industrial TFT LCD Display Manufacturer & Global LCD Supplier
2024-09-29
5104
The application range of 10.1-inch is very wide, including factory automation, vehicle-mounted equipment, self-service terminal equipment, medical equipment, energy management system, traffic monitoring system, smart home and building automation. The display screen of this size can choose the appropriate resolution according to the actual requirements of the product. Common resolutions are 1280*800, 1024*600, 1280*720, 1920*1200. Generally, they are high-resolution displays with high-definition and high-quality images. The following are some of the compatible products.
l Type: TFT horizontal screen
l Display pixels: 1280x800
l
Dimensions (mm): 229.46x149.1x4.7
l VA size (mm): 10.1
l AA size (mm): 10.1
l Effective size mm: 216.96x135.6
l Application: medical, industrial control
l Viewing angle: full viewing angle
l Backlight/brightness: 1000cd/m2
l Pin: 40pin
l Interface mode: LVDS
l Special instructions: anti-static ESD 8KV
l Working temperature: -20~70℃
l Driver chip: T.B.D
Model: 10.1-inch TFT LCD display, capacitive touch screen, 1280x800 dot matrix, LVDS interface, IPS full viewing angle
Sunlight readable/TFT-H101D13WXIWZKN40
l Type: TFT horizontal screen
l
Display Pixels：1280x800
l Dimensions (mm) ：229.46x149.10x4.70
l VA size(mm)：10.1
l AA size (mm) ：10.1
l Effective size mm：216.96x135.60
l Application: automotive, medical, industrial control
l Viewing angle: IPS full viewing angle
l Backlight/Brightness：1000cd/m2
l Pinout：FPC-40PIN
l Interface：LVDS 24 Bit
l Special note: With capacitive touch function
l Operating temperature：-20~70℃
l Supply voltage：3.3V
l Driver chip：T.B.D
l Type: TFT vertical screen
l Display Pixels：800x1280
l
Dimensions (mm) ：240.58x159.36x4.45
l VA size(mm)：10.1
l AA Size (mm) ：10.1
l Effective size (mm)：216.58x135.36
l Application: Tablet PC
l Viewing angle：Full view
l Backlight/Brightness：180cd/m2
l Pinout：40PIN
l Interface：MIPI
l Special instructions: Anti-static ESD 8KV
l Operating temperature：-20~70℃
l Supply voltage：3.3v
l Driver chip：EK79029+GT7291
Model: 10.1 inches 1280*800 resolution/IPS full viewing angle LVDS interface/TFT module/sunlight readable/
capacitive touch screen/TFT-H101A10WXIFT8C40
l Type: TFT horizontal display
l Display Pixels：1280x800
l
外形尺寸(mm) ：229.10x148.90x4.35
l VA尺寸(mm)：10.1
l AA尺寸(mm) ：10.1
l Effective size (mm)：216.96x135.60
l Application: automotive, medical, industrial control
l Viewing angle: full viewing angle
l Backlight/Brightness：800cd/m2
l Pinout：40pin
l Interface：LVDS
l Special note: With capacitive touch function
l Operating temperature：-20~70℃
l Supply voltage：3.3V
l Driver chip：EK79202B1
Model: 10-inch TFT|10.1-inch TFT horizontal screen|1280*800IPS wide viewing angle|LVDS interface|
Thickness 5.0 high brightness/TFT-H101A10WXIFTKN40
l Type: TFT horizontal screen
l
Display Pixels：1280x800
l Dimensions (mm) ：229.16x148.8x4.7
l VA Size(mm)：10.1
l AA Size(mm) ：10.1
l Effective size (mm)：216.96x135.6
l Viewing angle：Full view
l Backlight/Brightness：1000cd/m2
l Pinout：FPC-40PIN
l Interface：LVDS
l Special instructions: Anti-static ESD 8KV
l Operating temperature：-20~70℃
l Supply voltage：3.3v
l Driver chip：EK79202B1(TFT)
TFT LCD display with a resolution of 1024*600:
l Type: TFT module with board
l Display Pixels：1024x600
l Dimensions (mm) ：251.0x153.0x10.0
l
VA Size (mm)：10.1
l AA size (mm) ：10.1
l Effective size (mm)：222.72x125.28
l Application: automotive, medical, industrial
control
l Viewing angle：6H
l Backlight/Brightness：300cd/m2
l Pinout：USB+RS232
l Interface：UART/RS232
l Special instructions: Anti-static ESD 8KV
l Operating temperature：-20~70℃
l Supply voltage：5.0V
l Type: TFT horizontal screen
l Display Pixels：1024x600
l
Dimensions (mm) ：235.00×143.00×3.00
l VA Size (mm)：10.1AA尺寸(mm) ：10.1
l VA Size (mm)：222.72x125.28
l Application: automotive, medical, industrial control
l Viewing angle: full viewing angle
l Backlight/Brightness：300cd/m2
l Pinout：50pin
l Interface：TTL
l Special instructions: Anti-static ESD 8KV
l Operating temperature：-20~70℃
l Supply voltage：3.3V
l Driver chip：EK79001+EK73215
l Type: Driver-free module
l Display Pixels：1024x600
l
Dimensions (mm) ：258x148x6.5
l VA Size(mm)：10.1
l AA Size(mm) ：10.1
l Effective size (mm)：225.4x127.9
l Application: automotive, medical, industrial
control
l Viewing angle: full viewing angle
l Backlight/Brightness：1000cd/m2
l Interface：VGA
l Special instructions: Anti-static ESD 8KV
l Operating temperature：-20~70℃
l Supply voltage：12.0V
l Driver chip：T.B.D
l Type: TFT horizontal screen
l Display Pixels：1024x600
l
Dimensions (mm) ：235.0x143.0x5.0
l VA Size (mm)：10.1
l AA Size(mm) ：10.1
l Effective size （mm）（：222.72x125.28
l Application: Industrial control instruments, charging piles
l Viewing angle: full viewing angle
l Backlight/Brightness：1000cd/m2
l Pinout：40PIN
l Interface：LVDS
l Special note: Can be equipped with CTP
l Operating temperature：-20~70℃
l Supply voltage：3.3V
l Driver chip：EK79001+EK73215
l Type: TFT horizontal screen
l Display Pixels：1024x600
l
Dimensions (mm) ：235.0x143.0x5.0
l VA Size (mm)：10.1
l AA size (mm) ：10.1
l Effective size （mm）：222.72x125.28
l Application: industrial control equipment,
vehicle-mounted instruments
l Viewing angle: full viewing angle
l Backlight/Brightness：1000cd/m2
l Pinout：50PIN
l Interface：RGB
l Special note: Can be equipped with CTP
l Working temperature: -20~70 degrees
l Supply voltage：3.3V
l Driver chip: EK79001+EK73215
l Type: TFT horizontal screen
l Display Pixels：1024x600
l
Dimensions (mm) ：235.0x143.0x3.0
l VA尺寸(mm)：10.1
l AA尺寸(mm) ：10.1
l Effective size （mm）：222.72*125.28
l Application: Tablet PC
l Viewing angle: Full view
l Backlight/Brightness：300cd/m2
l Pinout：FPC-40PIN
l Interface：LVDS
l Special note: Can be equipped with CTP
l Operating temperature：-20~70℃
l Supply voltage：3.3v
l Driver chip：EK79001+EK73215
l Type: Car TFT
l Display Pixels：1280x720
l Dimensions (mm) ：238.8x148.0x7.0
l VA尺寸(mm)：10.1
l AA尺寸(mm) ：10.1
l Effective size （mm）：224.64x126.36
l Application: Automotive Instruments
l Viewing angle: full viewing angle
l Backlight/Brightness：600cd/m2
l Pinout：60PIN/FH52-60S-0.5SH
l Interface：LVDS
l Special instructions: Automotive grade
l Operating temperature：-30~85C
l Supply voltage：3.3V
TFT LCD display with a resolution of 1920*1200:
l Type: TFT horizontal screen
l Display Pixels：1920x1200
l
Dimensions(mm) ：230.20x150.00x21.55
l VA Size (mm)：10.1
l AA size (mm) ：10.1
l Effective size （mm）：216.81x135.50
l Application: automotive, medical, industrial control
l Viewing angle: full viewing angle
l Backlight/Brightness：1000cd/m2
l Interface：VGA
l Special instructions: Anti-static ESD 8KV
l Operating temperature：-20~60℃
l Supply voltage：12.0V
l Driver chip：T.B.D
For more related product information, please contact us directly!
