▶ 型号: HTM640200-47W
▶ 类型：标准COB液晶模组
▶ 显示像素：640x200
▶ 外形尺寸(mm) ：260x110.4x9.4
▶ VA尺寸(mm)：216.0x83.2
▶ AA尺寸(mm) ：211.17x79.17
▶ 点间距mm：0.396x0.366
▶ 应用：纺织机
▶ 视角：12H
▶ 背光/亮度：白光
▶ 引脚：17PIN
▶ 接口方式：MCU
▶ 工作温度：-20~70℃
▶ 供电电压：5.0V
单色COG/图形COB/字符COB/OLED模组/E-paper模组/段码屏 8051测试板
单色COG/图形COB/字符COB/OLED模组/E-paper模组/段码屏 STM32测试板
字符图形点阵模组专用转接板
单排排针连接器
COB 20针脚 连接线 底座/字符/图形点阵
HTM640200-41W | 单色图形模块| 640X200 像素 | 透射式液晶显示器| 白色 背光 | DFSTN (-) 负片显示 | 内置负电压 | 中、英、俄、日等字体可供选择
这款 HOTLCD 640x200 图形液晶显示模块在深黑色背景上显示明亮的白色像素。 这款透射式 LCD 显示屏经过精心设计，可在较暗的环境中使用时提供最佳的可视性和令人印象深刻的色彩。 显示屏内置强大的背光，可提供高对比度并确保屏幕上所有图形的可读性。
该图形 LCD 显示模块内置负电压，它还与 Arduino/C8051 完全兼容，可与其他电子系统无缝连接，适用于各种应用。 HTM640200 型号专为承受恶劣的工作条件而设计，在 -20 至 70 摄氏度的温度范围内使用时运行异常。 该 LCD 的最佳视角为 12:00，工作电压为 5V，并且符合 RoHS 标准。
Quality Standards
At HOTLCD Display We Strive Every Day To Provide Our Customers With The Highest Quality Products. This Means Quality, Engineering, And Manufacturing Teams Are Aligned To Exceed Your Expectations.
Our Customers Should Expect Their Products To Meet Or Exceed The Following Standards:
All Products
| Reliability Testing | Customers Can Expect All Production Parts To Meet Or Exceed Operational Requirements Over Temperature, Humidity, And Vibration. |
| Glass Cleanliness | Customers Can Expect Glass To Be Protected By Liners And Presented Mindful Of Cleanliness Standards. This Means Glass Will Be Clean Of Contaminants, Fingerprints, And Other Foreign Material. |
| Bezel Appearance | Bezels Will Be Uniformly Painted Free Of Foreign Materials And Distracting Cosmetic Blemishes. Our Standards Maintain A Clean Scratch-Free Surface. |
| PCB Appearance | PCB’s Are Delivered With Long-Term Reliability In Mind. Finishes Are Free Of Bubbles, Foreign Contaminants, And Meet All UL Fire Requirements. PCB Materials Will Always Be Delivered Within Industry Norms. PCB Edges Will Be Cleanly Cut And Void Of Burrs. |
| Soldering | Soldering Of All Leaded And SMT Components Is Consistent In Providing The Mechanical Security And Electrical Connectivity. |
| Consistency | Our Manufacturing And Inspection Processes Ensure Product Consistency From Lot To Lot. This Means Orders Processed Over The Years Will Continually Meet Your Expectations. We Do This By Exacting Manufacturing Specifications, With Attention To Detail In Our Processes, And By Comparing To The Golden Units. |
| Product Integrity | Quality In Product Manufacturing Ensures Integrity In Construction. Customers Can Expect Tight Assembly Without Worry Of Loose Parts Or Missing Material. Our Products Will Meet All Environmental Expectations Including Temp, Humidity, & Vibration Conditions. |
| Glass Color | While Normal Variations Of Glass Color May Occur (Due To Manufacturing Tolerances), Hotdisplay Display Maintains Color Compliance Per Internal Approved Color Charts. These Charts Are Maintained To Ensure Any Minor Glass Deviations Are Identified And Corrected As Needed. |
| ESD Protection & Safety | All Devices Are Designed And Handled In Consideration Of ESD Protection. This Includes ESD-SAFE Packaging Within Anti-Static Bags, Wraps, And Trays. Customers Are Reminded To Always Follow ESD Safety To Best Protect The Devices. |
